T24 Straight Gear – Polished
T27 Handwheel Gear (Spiral Bevel Type)
T40, 3 Holes, Marked, Non-polished
T40 spiral bevel gear with 3 holes, marked and non-polished is made of 20CrMo, with module 1 and pressure angle 20°. Manufactured through a series of precision processes, it weighs 0.0858kg. The 3-hole design facilitates easy assembly. Suitable for roller sewing machine transmission systems, it ensures stable and reliable operation.
TC1-4-23m1.5D18 Input Drive Gear
TCH500-0180-01S Straight Shaft Motor Spur Gear
TLY-008-C straight shaft motor spur gear is compatible with TCH500-0180-01S reducer. Constructed of 20CrMo steel, it features 20° pressure angle, module 2.5, 24 teeth and 35° helix angle. Its gear outer diameter is 65 mm, total length 65 mm and unit weight 0.5475 kg. Processed by gear hobbing, heat treatment and precision gear grinding, this gear features high precision and stable wear-resistant transmission for reducer power transmission.
TCH500-0190-00 Worm Spur Gear
TLY-007-C worm matching spur gear is compatible with TCH500-0190-00 reducer. Made of 20CrMo steel, it has 20° pressure angle, module 2.5, 60 teeth and 1/100 transmission ratio. Its gear outer diameter is 155 mm, total length 25 mm and single weight 3.12 kg. Processed by rough hobbing, heat treatment and precision gear grinding, this gear delivers high precision, stable and wear-resistant transmission for reducers.
TCH630-0190-00 Worm Spur Gear
TLY-009-C worm matching spur gear fits TCH630-0190-00 reducer. Made of 20CrMo steel, it has 20° pressure angle, module 2.5, 45 teeth and 1/100 transmission ratio. Its gear outer diameter is 125 mm, total length 25 mm and unit weight 1.8565 kg. Processed by gear hobbing, heat treatment and precision gear grinding, it features high precision and stable wear-resistant transmission for reducers.
TE02A11700 Chuan-Type H-Shaft Main Spindle Gear
TE03A122011 Type D-Shaft No.4 Transmission Gear
TE03A13401 Chuan-Type D-Shaft No.5 Transmission Gear (High Speed)
TIGL060-XXX-1687 Left-hand (Gear Ground) and TIGL060-XXX-1687 Right-hand (Gear Ground)
SYDH-002-C1 (TIGL060-XXX-1687)
Right-hand spiral bevel gear. Parameters: pressure angle 20°, module 1.25, 25 teeth, gear ratio 1, spiral angle 35°(R). Inner diameter 12 mm, outer gear diameter 31.75 mm, overall length 11.23 mm, weight 0.0333 kg. Made of 20CrMo with multiple precision processes. Wear-resistant and low-noise, matched for sewing equipment.
