Gear 1, 60T Left-Hand (Module 1.5, 60 Teeth) and Gear 2, 60T Left-Hand (Module 1.5, 60 Teeth) and Gear 3, 30T Right-Hand (Module 1.5, 30 Teeth)
HAT085 (1:1) Left-hand Bevel Gear
HYD-158-C is HAT085(1:1) left-hand spiral bevel gear with 20° pressure angle, module 1.5, 23 teeth, speed ratio 1 and 35° left-hand spiral angle.
Manufactured from 20CrMo through turning, gear milling, heat treatment, shot peening, facing, gear grinding and wire-cut keyway processes.
It has high precision, good wear resistance and stable transmission performance, ideal for reducer transmission assembly.
HC-001-C and HC-002-C
HC-001-C and HC-002-C are a pair of 20CrMo spiral bevel gears for reducer transmission.
Both with 20° pressure angle and module 2; 15 teeth left-hand and 24 teeth right-hand respectively, with a speed ratio of 1.6.
Manufactured by sawing, turning, gear milling, heat treatment, shot peening, boring & facing and precision gear grinding.
They own high precision, good wear resistance and stable meshing performance, serving as professional matched gears for reducers.
HL-T19 Right-hand Gear
HL-T19 right-hand spiral bevel gear (exclusive for sewing machinery): 20° pressure angle, 1.3 module, 19 teeth, 35°/R spiral angle, 10mm inner diameter, 25mm shaft diameter, 24.7mm outer tooth diameter, 49.92mm overall length, 0.3003kg weight. Made of 20CrMo via multi-step precision processes, it meets the transmission needs of sewing equipment.
JY-FZ-T27 Input Power Head Gear
FZ-002-C is JY-FZ-T27 left-hand input power head spiral bevel gear for sewing equipment.
Parameters: 20° pressure angle, module 1.5, 27 teeth, speed ratio 1, 35° left-hand spiral angle.
Made of 20CrMo, processed by turning, gear milling, heat treatment, shot peening, wire-cut keyway and precision grinding.
It has high precision, good wear resistance and stable transmission, ideal for power head transmission of sewing machines.
KA09104 Small Steel Gear 15T
KA09104 Small Steel Gear 15T is a dedicated spiral bevel gear for reducers. Made of 20CrMnTi material, it has a pressure angle of 20°, a module of 1.54, 15 teeth, and a spiral angle of 10°/R, with a shaft diameter of 10mm, a tooth outer diameter of 28mm, a total length of 59.25mm, and a single weight of 0.0541kg. Manufactured via multiple precision machining and surface treatment processes, it delivers stable transmission and high wear resistance.
KA09105 Large Steel Gear 45T (KA09182)
KA09106-V1 Small Bevel Gear 17T
KA09107 Large Bevel Gear 34T
LCD859-1S Miniature Bevel Gear (Finished Product)
M0159M11 (180-1:1) Left-hand Large Bevel Gear and M0160M10 (180-1:1) Right-hand Large Bevel Gear
M0201M11 (180-1:2) Left-hand Large Bevel Gear and M0202M10 (180-1:2) Right-hand Large Bevel Gear
Two large spiral bevel gears for reducers made of 20CrMnTi, with module 4.5, 20° pressure angle and speed ratio 2, precision-machined. AEP-13-C is a 15-tooth left-hand gear, and AEP-14-C is a 30-tooth right-hand gear, with obvious differences in size and weight, suitable for different direction transmission needs of reducers.
