M0215M10 (090-1:1) Left-hand Gear (without keyway) and M0216M10 (090-1:1) Right-hand Gear (without keyway)
M0217M10 (120-1:1) Left-hand Gear (without keyway) and M0218M10 (120-1:1) Right-hand Gear (without keyway)
M0217M10 (120-1:1) Left-hand Gear and M0218M10 (120-1:1) Right-hand Gear
M0239G10 Bevel Gear, Left-hand and M0240G10 Bevel Gear, Right-hand
M0292M10 (140-1:1) Output Bevel Gear (without keyway) and M0291M10 (140-1:1) Input Bevel Gear (without keyway)
M0292M10 (140-1:1) Output Bevel Gear and M0291M10 (140-1:1) Input Bevel Gear
M0313M10 (060-1:2) Input Bevel Gear and M0314M10 (060-1:2) Output Bevel Gear
M0341M10 (120-1:2) Input Bevel Gear and M0342M10 (120-1:2) Input Bevel Gear
M0354M10 (140-1:2) Large Bevel Gear and M0353M10 (140-1:2) Small Bevel Gear
A set of matched spiral bevel gears (large and small) for reducers made of 20CrMnTi, with module 2.94, 20° pressure angle and speed ratio 2. AEP-09-C is a 34-tooth right-hand large bevel gear, and AEP-10-C is a 17-tooth left-hand small bevel gear, precision-machined for 2:1 speed ratio transmission of reducers.
M1.5-27R Bevel Gear, Right-hand and M1.5-27L Bevel Gear, Left-hand
NBRX-1530 Short-Type – φ8 Gear and NBRX-1530-T24 Long-Type Gear
The NBRX-1530 series of spiral bevel gears (including the short type φ8 and the long type T24) are made of 20CrMo material and manufactured through multiple precision processes. With parameters of 20° pressure angle, 0.9 module and 24 teeth, their helix angles are 35° left-hand rotation and 35° right-hand rotation respectively, and the tooth outer diameter is 21.8mm. The short type has a total length of 10.5mm and a weight of 0.0148kg, while the long type has a total length of 16mm and a weight of 0.0235kg. Specifically designed for sewing equipment, these gears feature stable transmission, wear resistance and durability.
Pattern Comb Rotating Shaft and JBJ-000-002-078 Gear 2
NX-001-C Pattern Comb Rotating Shaft
20CrMnTi spiral bevel gear shaft, 20° pressure angle, module 3, 37 teeth, 35° left-hand spiral angle.
Processed by turning, gear milling, heat treatment, shot blasting and gear grinding. High precision and wear resistance, dedicated for sewing equipment transmission.
NX-002-C Gear 2
20CrMnTi right-hand spiral bevel gear with 20° pressure angle, module 3 and 37 teeth.
Equipped with wire cutting keyway on the basis of standard precision processing. Stable transmission, professionally matched for sewing machinery.
