Spiral Bevel Gears

The NBRX-1530 series of spiral bevel gears (including the short type φ8 and the long type T24) are made of 20CrMo material and manufactured through multiple precision processes. With parameters of 20° pressure angle, 0.9 module and 24 teeth, their helix angles are 35° left-hand rotation and 35° right-hand rotation respectively, and the tooth outer diameter is 21.8mm. The short type has a total length of 10.5mm and a weight of 0.0148kg, while the long type has a total length of 16mm and a weight of 0.0235kg. Specifically designed for sewing equipment, these gears feature stable transmission, wear resistance and durability.

1. T20 Spiral Bevel Gear: Material 20CrMo, pressure angle 20°, module 1, number of teeth 20, spiral angle 35°/L, inner diameter 8mm, outer diameter 21.5mm, total length 14.1mm. Manufactured through multiple precision processes, it is a dedicated transmission gear for roller sewing machines.
2. T24 Long Version Spiral Bevel Gear: Material 20CrMo, pressure angle 20°, module 1, number of teeth 24, spiral angle 35°/L, inner diameter 7.94mm, outer diameter 24.5mm, total length 14.35mm, single weight 0.0213kg. With precise craftsmanship, it is suitable for the transmission needs of roller sewing machines.

1. STRA030-G04-A Drive Bevel Gear: Spiral bevel gear made of 20CrMnTi, with module 2.175, pressure angle 20° and transmission ratio 1. Manufactured via a series of precision processes, it is suitable for reducer transmission systems, weighing 0.0825kg with stable and high-precision transmission performance.
2. STRA030-G04-B Driven Bevel Gear: Spiral bevel gear made of 20CrMnTi, with module 2.175 and pressure angle 20°. It is matched with STRA030-G04-A Drive Bevel Gear, produced by precision processes, weighing 0.0658kg, and serves as a reliable component for reducer transmission.

1. T16 φ5 Custom-made for Yinxiang Spiral Bevel Gear: Made of 20CrMo, with module 1 and pressure angle 20°. Manufactured via a series of precision processes, it weighs 0.0149kg. Custom-built for Yinxiang roller sewing machines, it features stable transmission, rust and wear resistance.
2. T16 Custom-made for Yinxiang φ7 Spiral Bevel Gear: Crafted from 20CrMo, with module 1 and pressure angle 20°. Produced with sophisticated technology, it weighs 0.0127kg. Suitable for Yinxiang roller sewing machines, it ensures stable operation and long service life.

Top Feed Spiral Bevel Drive Gear (exclusive for sewing machinery): 20° pressure angle, 1 module, 26 teeth, 35°/L spiral angle, 7mm inner diameter, 26mm outer tooth diameter, 12.7mm overall length, 0.0294kg weight. Made of 20CrMo via multi-step precision processes, it meets the transmission needs of the top feed mechanism of sewing equipment.

1. Z-91-188080-15 Gear: Spiral bevel gear with module 1, pressure angle 20° and helix angle 0°/L. It has an inner diameter of 8mm and addendum circle diameter of 20mm, suitable for sewing equipment with stable transmission performance, serving as a dedicated transmission component for sewing machinery.
2. Z-91-188032-15 Gear: Spiral bevel gear with module 1 and pressure angle 20°, as well as helix angle 0°/R. It has a compact size, high compatibility with sewing equipment, stable operation, and helps improve the working efficiency of sewing equipment.
